Kiosk Receipt 3 Inch Thermal Printer Mechanism Small Size For Pos Machine Ticket

Product Categories

Shenzhen Tousei Technology Co., Ltd.

Contact Now

Name: Kiosk Receipt 3 Inch Thermal Printer Mechanism Small Size For Pos Machine Ticket
Brand: WOOSIM
Price: 1 USD

Brand Name : WOOSIM

Model Number : PORTI-T380/BT300

Certification : CE,FCC,ROHS

Place of Origin : CHINA

MOQ : 1PC

Price : Negotiable

Payment Terms : L/C, T/T, Western Union

Supply Ability : 1000PCS/WEEK

Delivery Time : 5-8 work days

Packaging Details : carton 12pcs/carton

Paper loading : Auto paper loading

Cutter : Auto-cutter

Printing : Direct thermal line printing

Interface : support USB

MCU : 32bits RISC, FLASH : 4Mbytes, RAM : 8Mbytes

Power : 12-24V, 0.6A

Paper width : 80mm

Paper : Thermal roll paper

Size : small size

Receive buffer size : 1M

Contact Now

3 inch kiosk receipt thermal printer for pos machine ticket

PORTI-T380/BT300

- Very silent printing thru direct thermal printing method.

- High resolution(203dpi : 8dots/mm). - Supports text and graphic printing.

- Easier maintenance with self-diagnostics.

- Microsoft Widows XP / VISTA / 10/ Anroid

- Flow control : Software (XON/XOFF)

※ Hardware flow control not supported in printer

Item	Specification
Printing method	Direct thermal line printing
Characters per line	64cpl (MAX)
Character size	Eng. : 9x24dots, 12x24dots Kor. : 16x24dots [24x24dots]
Resolution	203dpi, 8dots/mm
Optional Characters	Simplified/Traditional Chinese, Arabic, Cyrillic, Russian, Tukish,Greek, Japanese, Persian, Latin9 and Others upon request.
Print width	3-inch (72mm, 576dots)
Printing speed	150mm/sec (MAX)
Dimensions (WxDxH)	169 * 88.2 * 101 mm
Weight	980g
Interface	UART(RS-232C or TTL) [Standard model]
Paper supplied	Thermal roll paper (80mm wide, 80ø), Paper thickness : 60±5㎛
Barcode supported	1-dimension : Code128, Code39, I2/5, Code93, UPC-A, UPC-E, EAN8, EAN13, CODABAR 2-dimension : PDF417, QR Code, DATA Matrix, Micro PDF417, Truncated PDF417
Driver	Microsoft Widows XP / VISTA / 10 Windows CE, Linux, Android, Blackberry
H/W Spec	MCU : 32bits RISC, FLASH : 4Mbytes, RAM : 8Mbytes
Receive buffer size	1M bytes
Input power	24VDC, Standby 60mA and MAX 3A
Option	Sliding mount assembly
Operating temperature	-10°C ~ 50°C
Storage temperature	-10°C ~ 70°C
MCBF(Mean Cycle Between failure)	Mechanical	37,000,000 lines
	Head	Approximately 50Km

Kiosk Receipt 3 Inch Thermal Printer Mechanism Small Size For Pos Machine Ticket
